Nvent Caddy MCS100 MC/AC cable support bracket 14-3 to 10-2 MC/AC 8 cable

Product Description

The NVENT MCS100 is an MC/AC Cable Support Bracket constructed from electro-galvanized steel. It is designed to support 10/2 AWG Super Neutral Cable and 14/3 to 10/2 AWG MC/AC Cable. This bracket accommodates up to 8 cables with an outer diameter ranging from 0.43 to 0.56 inches, featuring 1/4 inch and 0.2 inch holes for secure installation. It helps manage electrical wiring efficiently.

• Neatly isolates, supports and secures MC/AC cables
• Properly spaces MC/AC cable to help eliminate bundling and NEC and CEC derating issues
• Results in a "neat and workmanlike" installation

Product Highlights

Electro-galvanized steel bracket for MC/AC cable support, preventing bundling and ensuring organized installations.

Product Information

Standard Information

• Brand: NVENT
• Manufacturer Part Number: MCS100

Technical Specifications

• Finish: Electro-Galvanized
• Cable Specifications: 8 Cable, 0.43 to 0.56 in OD, 1/4 in and 0.2 in Hole
• Suitable For Use With: 10/2 AWG Super Neutral Cable and 14/3 to 10/2 AWG MC/AC Cable
• Manufacturer: nVent
• Application: Electrical Applications
• Material: Steel
• Standards/Approvals: cULus Listed, NEC Certified, CEC Certified, BABA Compliant, RoHS Compliant
• MC/AC Cable Size: 14-3 to 10-2
• Super Neutral Cable Size: 10-2
• Cable Capacity: 8
• Hole Size 1: 1/4"
• Hole Size 2: 0.2"
• Outer Diameter: 0.430" - 0.56"
• Static Load Rating: 15 lb (67 N) for 4Z parts installed on 3/8" (M10) smooth rod in the F2 direction
• Type: Brackets and Hangers
