Nvent AFAB3 Threaded Angle Bracket 3/16 Inch

Product Description

The NVENT AFAB3 is a 3/16-inch threaded angle bracket designed for structural support and equipment mounting in trade installations. This bracket provides a rigid, threaded attachment point for securing conduit, piping, ductwork, or other mechanical system components to structural surfaces. The threaded design eliminates the need for additional hardware in many applications and speeds up installation. Electricians, plumbers, and mechanical contractors rely on this type of hardware when a secure, angle-mounted fastening solution is required in tight or demanding service environments.

This angle bracket is suited for use in commercial and residential mechanical, electrical, and plumbing installations where a threaded mounting point at an angled orientation is required. It is commonly installed during rough-in phases of construction or during retrofit work where existing supports need reinforcement or replacement. The 3/16-inch thread size fits standard fastener and rod specifications common in light structural support applications.

Key Features

• 3/16-inch threaded connection for direct fastener engagement
• Angle bracket design provides a rigid, two-plane mounting surface
• Compatible with standard trade fastening hardware and threaded rod
• Compact form factor suits tight installation spaces
• Weighs 5.5 pounds, indicating a solid, heavy-duty construction

Compatibility

Designed as an OEM-style replacement or direct-use threaded angle bracket for mechanical, electrical, and plumbing support applications requiring a 3/16-inch threaded mount.

Installation Notes

Installation is typically performed by licensed electricians, plumbers, or mechanical contractors as part of a support or mounting assembly. Power down or shut off the relevant system before working near live circuits or pressurized lines. Follow applicable NEC, IPC, or IFGC guidelines for support spacing and fastener requirements. Use appropriate tools to ensure the bracket is seated flush and fasteners are fully engaged before returning the system to service.

Technical Specifications

• Thread Size: 3/16 inch
• Weight: 5.5 pounds
• UPC: 78285643891

Standard Information

• Brand: NVENT
• Manufacturer Part Number: AFAB3
