nVent A16106CH Hof Piano Hinge JIC Box 16 in H x 10 in W x 6 in D

Product Description

The nVent A16106CH is a junction box designed for various electrical applications. It measures sixteen inches in height, ten inches in width, and six inches in depth. The box has a continuous hinged design with a screw clamp cover, suitable for NEMA 12/13/IP65 ratings. It is constructed from steel with a polyester powder painted finish.

• Durable steel construction
• NEMA 12/13/IP65 rating for protection
• Wall mounting capability for versatile installation

Product Highlights

This junction box is ideal for secure closure and is suitable for multiple applications. Its hinged cover provides easy access to internal components.

Product Information

Standard Information

• Manufacturer: nVent
• Product Name: Hof Piano Hinge JIC Box

Technical Specifications

• Application: For secure closure and can be used in a wide variety of applications
• Color: Gray
• Cover Type: Continuous Hinged/Screw Clamp
• Depth: 6 inches
• Finish: Polyester Powder Painted
• Height: 16 inches
• Manufacturer Part Number: A16106CH
• Material: Steel
• Mounting Type: Wall
• NEMA Rating: NEMA 12/13/IP65
• Panel Size: 14.75 x 8.88 inches
• Series: A51CH
• Standards/Approvals: cUL Listed per CSA C22.2 File No. 94 File No. E27567|CSA File No. 42184|IEC 60529|UL 50/50E Listed File No. E27567
• Width: 10 inches
