Nvent 6TI912 H-Ti/T Rod to Flange Clip, M10 Hole, Threaded, 14.3–19.1 mm Flange

Product Description

The NVENT 6TI912 H-Ti/T Rod to Flange Clip suspends threaded rods from beam flanges. The threaded rod hanger can swivel to provide a vertical dropdown. It requires only a hammer to install. It is made of spring steel with nVent CADDY Armour finish.

• Suspends threaded rod from beam flanges
• Threaded rod hanger can swivel to provide a vertical dropdown
• Requires only a hammer to install

Product Highlights

The NVENT 6TI912 is a rod to flange clip that suspends threaded rods from beam flanges and requires only a hammer to install.

Product Information

Standard Information

• Brand: NVENT
• Manufacturer Part Number: 6TI912
• Country of Origin: US - United States

Technical Specifications

• Material: Spring Steel
• Finish: nVent CADDY Armour
• Hole Size (HS): 10 mm
• Hole Type: Threaded
• Flange Thickness (FT): 14.3 - 19.1 mm
• Static Load: 885N
• UPC: 782856134060
• EAN: 0782856134060
• Series: HTI/TR
• Specifications: 3/8 in Rod
• Suitable For Use With: Beam/Purlin
• Type: Seismic
• Flange Size: 9/16 to 3/4 in
• Load Capacity: 200 lb Static
• Mounting Type: Flange
• Rod Size: 3/8 in
• Fitting Type: Beam Clip, Rod Hanger
• Hole Size: 0.375 in
• Flange Thickness: 14.3 - 19.1 mm
