nVent 569251 ERIFLEX Distribution Block, 1000 VAC/1000/1500 VDC, 400 A, 1 Pole, 2 Primary Connections, 12 Secondary Connections

Product Description

The nVent ERIFLEX 569251 Distribution Block offers reliable electrical distribution. Rated for 1000 VAC and 1000/1500 VDC, this block supports up to 400 A. It features one pole with two primary connections and twelve secondary connections. This model is suitable for wire sizes ranging from eight to three aught AWG and fourteen to six AWG. The unit is made of aluminum and thermoplastic materials and has tinned finishes for improved conductivity and compatibility.

• Supports half-inch to three aught AWG conductors.
• Includes two primary and twelve secondary connections per pole.
• Mounts easily on DIN rails or panels.

Product Highlights

This product is a standard choice for solar applications due to its robust design and ratings.

Product Information

Standard Information

• Manufacturer: nVent
• UPC: 78285668761

Technical Specifications

• Amperage Rating: 400 A
• Application: Solar Applications
• Dimensions: 3.79 inches H x 2.2 inches W x 1.99 inches D
• Finish: Tinned
• Material: Aluminum/Thermoplastic
• Number of Poles: 1
• Primary Connections: 2
• Secondary Connections: 12
• Short Circuit Current Rating: 10 kA
• Standards/Approvals: CE Certified, cULus Listed, EAC Approved, RoHS Compliant
• Voltage Rating: 1000 VAC/1000/1500 VDC
