Numatics INB105-104-021 Pneumatic Connector with Brass Release Ring and Buna-N O-Ring 1/4 in Tube x FNPT

Product Description

Numatics Pneumatic Connector, MPN INB105-104-021, is designed for precise tubing applications. This connector fits a quarter-inch tube and connects to female NPT threads. It features brass construction with a nickel plating that enhances durability. The maximum pressure rating is two hundred sixty-five psi, making it suitable for various pneumatic systems.

• 1/4 inch nominal size
• Pressure rating of 265 psi
• Temperature range from -20 to 176 degrees Fahrenheit

Product Highlights

This pneumatic connector optimizes air flow and seals reliably, ideal for use in air compressor and pneumatic tool systems.

Product Information

Standard Information

• Brand: Numatics
• Manufacturer: Emerson Electric

Technical Specifications

• Finish: Nickel Plated
• Series: INB
• Material: Brass
• Nominal Size: 1/4 in
• End Style: Tube x FNPT
• Hex Size: 1/2 in
• Pressure Rating: 265 psi
• Temperature Rating: -20 to 176 degrees Fahrenheit
• Dimensions: 0.5 in W x 0.669 in H
• Fitting/Connector Type: Connector
