Numatics INB105-104-020 Pneumatic Connector 1/4 x 1/8 in Tube x FNPT

Product Description

The Numatics Pneumatic Connector with part number INB105-104-020 is designed for efficient air flow in pneumatic systems. This connector features a nickel-plated brass construction that ensures durability and resistance to corrosion. It connects tubing with a nominal size of one-quarter by one-eighth inches to female NPT threads, making it suitable for a variety of applications.

• Brass material with nickel plating for added durability.
• Pressure rating of 265 PSI for reliable performance.
• Temperature range from minus twenty to one hundred seventy-six degrees Fahrenheit.

Product Highlights

This connector is ideal for use in domestic applications requiring secure connections in compressed air systems.

Product Information

Standard Information

• Brand: Numatics
• Manufacturer: Emerson Electric

Technical Specifications

• Dimensions: 0.5 in W x 0.551 in H
• Domestic/Import: Domestic
• End Style: Tube x FNPT
• Finish: Nickel Plated
• Fitting/Connector Type: Connector
• Hex Size: 1/2 in
• Material: Brass
• Nominal Size: 1/4 x 1/8 in
• Pressure Rating: 265 PSI
• Series: INB
• Temperature Rating: -20 to 176 deg F
