Numatics INB103-308-022 Pneumatic Connector With Brass Release Ring and Buna - 3/8 In Tube x MNPT

Product Description

The Numatics Pneumatic Connector with the MPN INB103-308-022 is designed for pneumatic applications. This connector features a push-in fitting with a brass release ring and a Buna-N O-ring, ensuring reliable performance. Ideal for connecting a tube with a 3/8-inch nominal size to an MNPT fitting, it is suitable for various industrial uses.

• Push-in design for easy attachment
• Brass construction for durability
• Temperature range of -20 to 176 degrees Fahrenheit

Product Highlights

This pneumatic connector is made from nickel-plated brass, providing strength and resistance to corrosion. It offers a pressure rating of 265 psi, making it suitable for high-pressure applications.

Product Information

Standard Information

• Manufacturer: Emerson Electric
• Brand: Numatics

Technical Specifications

• Dimensions: 0.687 inches wide x 0.787 inches high
• Domestic/Import: Domestic
• End Style: Tube x MNPT
• Finish: Nickel Plated
• Fitting/Connector Type: Connector
• Hex Size: 11/16 inches
• Material: Brass
• Nominal Size: 3/8 inches
• Pressure Rating: 265 psi
• Series: INB
• Temperature Rating: -20 to 176 degrees Fahrenheit
