Numatics INB103-102-022 Pneumatic Connector With Brass Release Ring and Buna N O-Ring 1/2 x 3/8 in Tube x MNPT Brass Domestic

Product Description

The Numatics Pneumatic Connector, MPN INB103-102-022, is designed for various pneumatic applications. This connector features a size of one-half inch by three-eighths inch, with a tube to MNPT configuration. The robust brass material and nickel plating enhance durability and resistance. Ideal for systems operating up to two hundred sixty-five psi and a temperature range of minus twenty to one hundred seventy-six degrees Fahrenheit.

• Durable brass construction
• Pressure rated up to 265 psi
• Temperature tolerance from -20 to 176 degrees Fahrenheit

Product Highlights

Reliable and strong, this connector meets industry standards for various pneumatic fittings.

Product Information

Standard Information

• Brand: Numatics
• Manufacturer: Emerson Electric

Technical Specifications

• Dimensions: 0.8125 inches W x 0.906 inches H
• End Style: Tube x MNPT
• Material: Brass
• Nominal Size: 1/2 x 3/8 inches
• Pressure Rating: 265 psi
• Temperature Rating: -20 to 176 degrees Fahrenheit
• Hex Size: 13/16 inches
• Finish: Nickel Plated
• Series: INB
