Numatics INB101-104-000 Bulkhead Union with Brass Release Ring and Buna-N O-Ring

Product Description

The Numatics Bulkhead Union INB101-104-000 is designed for reliable connection in pneumatic systems. This product features a brass release ring and Buna-N O-ring for a secure fit. The fitting is suited for a nominal size of one fourth inch by M13 by one inch. It can withstand a pressure of two hundred sixty-five psi and operates within a temperature range of negative twenty to one hundred seventy-six degrees Fahrenheit.

• High-quality brass material
• Pressure rating of 265 psi
• Temperature rating from -20 to 176 degrees Fahrenheit

Product Highlights

This fitting is an excellent choice for durable and leak-free connections in various pneumatic applications.

Product Information

Standard Information

• Brand: Numatics
• Manufacturer: Emerson Electric

Technical Specifications

• Fitting/Connector Type: Union
• Nominal Size: 1/4 in x M13 x 1 in
• Material: Brass
• Finish: Nickel Plated
• Hex Size: 0.63 in
• Pressure Rating: 265 psi
• Temperature Rating: -20 to 176 deg F
• Domestic/Import: Domestic
