NSI Industries NPDB-11-2/0-1 NPDB Line 1X2/0-1

Product Description

The NSI Industries NPDB-11-2/0-1 is a power distribution block rated for a short circuit current of 100kA. It features a single primary line and single secondary load configuration. This product supports wire sizes from 2/0 to 14 AWG for both line and load. It is constructed with Valox Nylon 6/6 and equipped with finger-safe Lexan 500R Polycarbonate panels and covers. The connector is made of high-conductivity 6061-T6 Electro-Tin plated aluminum alloy.

• Modular design for flexible installation
• DIN rail mountable with locking mechanism
• Compatible with copper or aluminum conductors

Product Highlights

This block can function as a standalone unit or be combined with other blocks for a multi-block setup, catering to various installation needs.

Product Information

Standard Information

• Catalog Number: NPDB-11-2/0-1
• Brand: NSI Industries

Technical Specifications

• Size: Length 3.55 inches - Width 1.03 inches - Height 2.62 inches
• Voltage: 600 Volt
• Amperage: 175 Amp
• Material: Aluminum
• Max Temperature: 90 degrees C
• Warranty Length: 1 year
• Country of Origin: India
• Applications: Splicing or tapping of primary conductors to secondary side conductors
