Nsi Industries L225 limit switch 120/240 V 30/60 A quick-disconnect switch

Product Description

The NSI INDUSTRIES L225 is a bimetal disc temperature control limit switch designed for reliable operation. It handles loads up to 25 amps at 240VAC and features a 3/4 inch (19mm) design. This quick-disconnect switch has an opening temperature of 225°F and a closing temperature of 185°F, with a 40°F differential. It is suitable for various electrical applications requiring precise temperature control.

• 1/4 inch quick disconnect terminals
• 60T electrical ratings
• Close when temperature differential is reached

Product Highlights

Reliable bimetal disc temperature control with quick-disconnect terminals and precise temperature settings.

Product Information

Standard Information

• Brand: NSI INDUSTRIES
• Manufacturer Part Number: L225

Technical Specifications

• Differential Temperature: 40°F
• Certifications: UL, CSA
• Amperage Rating: 30/60 A
• Closing Temperature: 185°F
• Full Load Amps (FLA) at 120VAC: 10A
• Full Load Amps (FLA) at 240VAC: 5A
• Locked Rotor Amps (LRA) at 120VAC: 60A
• Locked Rotor Amps (LRA) at 240VAC: 30A
• Opening Temperature: 225°F
• Pilot Duty Rating: 125 VA at 120/240VAC
• Resistive Load Amps (RLA): 25A at 120/240VAC
• Switch Type: Quick-Disconnect
• Voltage Rating: 120/240V
