Nsi G-2-S Bronze Ground Clamp for Water Pipe, 1-1/4 inches to 2 inches Pipe

Product Description

The NSI G-2-S ground clamp is used for bonding bare copper wire to water pipe or as a water meter shunt. It is assembled with steel screws and features a lay-in design for flexibility. It fits 1-1/4" to 2" water pipes and accommodates 10 AWG to 2 AWG conductor sizes.

• Bonds bare copper wire to water pipes
• Can be used as a water meter shunt
• Assembled with steel screws

Product Highlights

The NSI ground clamp provides a flexible grounding solution for water pipe applications.

Product Information

Standard Information

• Brand: NSI
• Manufacturer Part Number: G-2-S
• Country of Origin: US

Technical Specifications

• Type: Ground Fittings
• Width: 0.75 Inches
• Height: 1.69 Inches
• Length: 3.6 Inches
• Material: Steel
• Standard: UL
• Wire Size: 10 AWG to 2 AWG
• Insulation: Non-Insulated
• Clamp Material: Bronze
• Country of Origin: US
• Conductor Type: Solid/Stranded Copper
• Pipe Size: 1-1/4 to 2 in
• Series: G-S Series
• Conductor Size: 10 AWG Solid to 2 AWG Stranded
• Installation: (2) Screw Connector to Pipe, (1) Screw Wire Connector
• Approval: UL (Canada and US)
• Used On: Bare Copper Wire to Pipe
• Brand: NSI
• Manufacturer: NSi Industries
• Model / MPN: G-2-S
• Product Type: HARDWARE_CLAMP_VISE
