NSI 5008ME 5008 Series Delayed Response Thermal Utility-Grade Turn Lock Photocontrol 480VAC

Product Description

The NSI 5008ME is a Turn Lock Photocontrol designed for utility-grade applications. It operates at 480 VAC and is suitable for street and highway lighting. Key features include delayed response timing to prevent false triggers from vehicle lights and a silicon photocell that reacts to light levels similar to the human eye. This device is built for durability, featuring a polycarbonate casing that withstands harsh environmental conditions.

• Designed for street and highway lighting applications
• Features delayed response to avoid false switching
• Constructed from durable, UV-stabilized polycarbonate

Product Highlights

Reliable performance in outdoor lighting setups with multiple safety features.

Product Information

Standard Information

• Manufacturer: NSi Industries
• UPN: 78626161020

Technical Specifications

• Application: Street and Highway Lighting Applications
• Arrester: 380 J
• Ballast Load: 4800 VA
• Color: Yellow
• Dimensions: 2.187 inches H x 3.187 inches W
• Environmental Conditions: -40 to 140 degrees F Operating Temperature
• Frequency Rating: 50/60 Hz
• Material: Polycarbonate
• Mounting Type: Twist-Lock
• Sensitivity: 1 to 3 FC (ON), 5 Max FC Average (OFF) to (ON) Ratio
• Sensor Type: Silicon Photo
• Series: 5008 Series
• Standards/Approvals: UL 773|ANSI C136.10|EEI Listed|cULus Listed
• Timing Range: 0 to 2 min
• Tungsten Rating: 7500 W
• Voltage Rating: 480 VAC
