Norton 69957345631 Abrasive Belt 60 Grit 1-1/2x60 in

Product Description

The NORTON 69957345631 is a coated abrasive belt engineered for aggressive stock removal and consistent cut performance. Built on a heavyweight Y-weight polyester backing, this belt handles high-tension applications without stretching or delaminating under load. The abrasive grain is ceramic alumina, a self-sharpening material that fractures to expose fresh cutting edges as it wears. Measuring 1-1/2 inches wide and 60 inches long, it fits standard belt grinders and file belt machines used across metalworking, fabrication, and tool-and-die shops. At 60 grit, it falls in the coarse range, making it well-suited for weld blending, deburring, and initial shaping passes. It supports both wet and dry operation.

This belt is a common choice in metal fabrication and maintenance environments where operators need a durable, high-cut-rate abrasive for ferrous and non-ferrous stock removal. The closed-coat construction maximizes grain coverage for faster material removal on flat or contoured workpieces. The R980P series designation places it in a performance tier built for demanding production and job-shop grinding tasks. Machinists, fabricators, and industrial maintenance technicians are the primary installers and users of this belt type.

Key Features

• Ceramic alumina grain self-sharpens during use for extended belt life
• Y-weight polyester backing resists stretching under high contact-wheel tension
• Closed-coat construction maximizes abrasive coverage and cut rate
• 60 grit coarse grade suited for weld removal, deburring, and rough shaping
• Supports wet and dry grinding operation
• 1-1/2 x 60 inch size fits standard file belt and bench-style belt grinders

Compatibility

Designed as a replacement abrasive belt for standard 1-1/2 x 60 inch belt grinders and file belt machines used in metalworking and fabrication applications.

Installation Notes

Belt installation should be performed with the machine powered off and all energy sources isolated per OSHA lockout/tagout procedures. Confirm belt tracking direction matches the arrow printed on the belt backing before tensioning. Inspect the contact wheel and platen for wear or damage before mounting a new belt. Wear appropriate PPE including eye protection and gloves during changeout and operation.
