Norton 66260195080 Diamond Dresser 7/16 Inch Shank

Product Description

The NORTON 66260195080 is a multi-point diamond dresser designed to true and dress abrasive grinding wheels in precision grinding applications. The tool features a 7/16-inch shank diameter and a 3/8-inch head length, making it well-suited for use in standard wheel dresser holders found on surface grinders, cylindrical grinders, and bench grinders. The multi-point diamond configuration distributes wear across several diamond points, extending service life compared to single-point designs. At 0.05 pounds, the tool is lightweight and easy to handle during setup. It ships in a package quantity of one.

This diamond dresser is used in machine shops, grinding operations, and maintenance environments where grinding wheel condition directly affects surface finish and dimensional accuracy. It is appropriate for truing wheels that have glazed, loaded, or lost their profile. The 1E-F shape designation and 5/16-inch head thickness make it compatible with standard dresser setups on light- to medium-duty grinding equipment. Machinists, tool and die makers, and maintenance technicians are the typical installers and users of this tool.

Key Features

• Multi-point diamond configuration for extended dresser life
• 7/16-inch shank diameter fits standard wheel dresser holders
• 3/8-inch head length suitable for typical wheel face dressing
• 5/16-inch head thickness for stable contact during dressing passes
• 1E-F shape designation for use in common dresser tool holders
• Lightweight at 0.05 pounds for easy handling and positioning

Compatibility

Designed as an OEM-style replacement or direct-use diamond dresser for grinding equipment that accepts a 7/16-inch shank diameter dresser tool in a standard holder.

Installation Notes

Diamond dressers are installed and used by machinists or grinding equipment operators. Before mounting or replacing a dresser, shut down the grinding machine and confirm the wheel has come to a full stop. Secure the dresser firmly in the holder to prevent movement during the dressing pass, as vibration can damage the diamond points. Follow the machine manufacturer's recommended feed rate and depth of cut for dressing operations.
