Norton 66252836967 Type 12 Grinding Wheel 6in 60 Grit

Product Description

The NORTON 66252836967 is a Type 12 grinding wheel designed for precision tool grinding and sharpening applications. Built with aluminum oxide abrasive and a vitrified bond, this wheel delivers consistent stock removal and surface finish on steel tooling and similar workpieces. The wheel runs at a maximum of 4,140 RPM and carries a K hardness code, placing it in the medium grade range. At 6 inches in diameter with a 0.5 inch thickness and a 3/8 inch face width, it is sized for bench grinders and surface grinding equipment used in tool rooms and maintenance shops.

This wheel suits tool room operators, machinists, and maintenance technicians who sharpen or re-profile cutting tools on bench or pedestal grinders. The aluminum oxide abrasive is well suited to ferrous materials including high-speed steel tool bits, drills, and lathe tools. The Type 12 form provides a defined face width for controlled contact on cutting edges. The 1-1/4 inch hole size fits standard arbors found on bench grinders commonly used in light industrial and trade shop environments.

Key Features

• Aluminum oxide abrasive for effective stock removal on ferrous tooling
• Vitrified bond provides rigidity and consistent form retention during grinding
• Type 12 wheel geometry with 3/8 inch face width for controlled edge contact
• K hardness code (medium grade) balances wheel life with cutting action
• 60 grit delivers medium material removal suitable for tool sharpening and reconditioning
• Maximum rated speed of 4,140 RPM for safe operation on compatible equipment

Compatibility

Designed as an OEM-style replacement or standard consumable for bench and pedestal grinders accepting a 6 inch diameter, 1-1/4 inch arbor hole Type 12 grinding wheel.

Installation Notes

Installation should be performed by a qualified machinist or maintenance technician following ANSI B11 and OSHA abrasive wheel safety guidelines. Always power down and lock out the grinder before mounting or removing a wheel. Inspect the wheel for cracks or chips before installation and perform a ring test on vitrified wheels per standard practice. Never exceed the maximum RPM rating of 4,140 stamped on the wheel.
