Norton 63642581587 Convolute Deburring Wheel 6 in Silicon Carbide

Product Description

The NORTON 63642581587 is a convolute deburring wheel designed for edge finishing, burr removal, and surface blending on metal workpieces. Built with silicon carbide abrasive at a fine grade, it delivers consistent cutting action on ferrous and non-ferrous metals. The convolute construction bonds abrasive grain throughout a non-woven fiber core, maintaining a uniform cut as the wheel wears. At density 9, the wheel provides a firm structure suited for aggressive deburring passes while still conforming to part geometry. Rated to 6,000 RPM, it is compatible with standard bench grinders and arbor-mounted setups. Machinists, fabricators, and tool room technicians are the primary installers and operators of this wheel.

This convolute wheel is used in metalworking and fabrication environments where consistent edge finishing is required after milling, drilling, stamping, or cutting operations. It is appropriate for both job shop and production floor settings. The 6 inch diameter and 1 inch face width fit standard bench grinder arbors with a 1 inch center hole, making it a direct fit for common shop equipment without adapters. Fine grade silicon carbide makes it well suited for finishing passes on aluminum, brass, titanium, and hardened steel where a smoother surface finish is the goal rather than stock removal.

Key Features

• Silicon carbide abrasive provides sharp, consistent cutting action on metal edges
• Convolute construction maintains uniform performance throughout the life of the wheel
• Density 9 firm structure supports controlled deburring without excessive deflection
• Fine grade suited for finishing passes and light burr removal
• 6,000 RPM rating compatible with standard bench grinder speeds
• 1 inch center hole fits common bench grinder and arbor spindle configurations

Compatibility

Designed for use on bench grinders and arbor-mounted finishing equipment with a 1 inch spindle bore accepting a 6 inch diameter convolute deburring wheel.

Installation Notes

Installation and operation should be performed by qualified machinists or metalworking technicians familiar with abrasive wheel safety. Always power down and isolate the grinder before mounting or removing the wheel. Verify that the machine spindle speed does not exceed the 6,000 RPM maximum rating marked on the wheel before startup. Appropriate eye protection, face shield, and guards must be in place before operating any abrasive wheel per ANSI B7.1 safety standards.
