Norgren TC-5/16-1 1/8X5 Rodless Air Cylinder

Product Description

The NORGREN TC-5/16-1 1/8X5 is a single-acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1-1/8 inch bore, a 5 inch stroke length, and a maximum working pressure of 150 psi. The port is sized at 1/8 NPTF and the rod thread is 5/16-18. This cylinder suits applications where a compact, space-efficient actuator is required. It is installed by millwrights, automation technicians, and mechanical maintenance professionals working with pneumatic motion systems. The square style body aids in secure panel or bracket mounting.

This cylinder is suited for light-duty single-acting pneumatic actuation tasks in industrial and manufacturing environments. The single-acting design uses air pressure for actuation in one direction, relying on a spring or external force for return. It is appropriate for applications such as clamping, indexing, and short-stroke linear movement where moderate bore size and controlled stroke length are required. The operating temperature range of -20 to 200 degrees F broadens its suitability across varied industrial conditions.

Key Features

• Single-acting design with 1-1/8 inch bore for compact pneumatic actuation
• 5 inch stroke length supports short-to-mid range linear motion requirements
• Maximum working pressure of 150 psi
• 1/8 NPTF port for standard pneumatic line connection
• 5/16-18 rod thread for direct load attachment
• Square style body for straightforward bracket or surface mounting
• Operating temperature range of -20 to 200 degrees F

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic actuator for single-acting rodless cylinder applications requiring a 1-1/8 inch bore and 5 inch stroke with 1/8 NPTF port connection.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or millwright. Before servicing or installing this cylinder, depressurize the pneumatic circuit completely and lock out the compressed air supply at the source. Verify that all port fittings and thread connections are properly sealed to prevent air leaks before returning the system to operating pressure. Follow applicable OSHA and machine safety standards for pneumatic actuator installation and guarding.
