Norgren RP200X3.000-DAD Rodless Air Cylinder 2in Bore 3in Stroke

Product Description

The NORGREN RP200X3.000-DAD is a double acting rodless air cylinder built for industrial pneumatic applications. It features a 2-inch bore and a 3-inch stroke, delivering linear motion without an external rod extending beyond the cylinder body. The stainless steel construction handles demanding environments where corrosion resistance matters. Maximum working pressure is 250 psi (17.2 bar), making it suitable for mid-range pneumatic circuits. The 1/4 NPTF port allows direct connection to standard pneumatic fittings. Licensed HVAC, mechanical, and industrial technicians regularly specify rodless cylinders where space constraints prevent conventional rod-style actuators.

This cylinder fits industrial automation, material handling, and machinery positioning applications where a compact actuator profile is required. The double acting design means pressurized air drives the carriage in both directions, eliminating the need for a return spring and providing controlled force on both the extend and retract strokes. The double end mount style allows secure fixture to a machine frame from both ends of the cylinder body. The overall body width of 2.08 inches keeps the footprint tight in confined mounting areas.

Key Features

• Double acting operation provides powered motion in both directions
• Stainless steel body for corrosion resistance in wet or wash-down environments
• 2-inch bore and 3-inch stroke for mid-range force and travel
• 250 psi maximum working pressure (17.2 bar)
• 1/4 NPTF port for leak-resistant tapered thread connections
• Double end mount style for rigid two-point attachment to machine frames
• Rod thread size 1/2-20 and mount thread 1-1/4-12 for standard hardware compatibility

Compatibility

Designed as an OEM-style pneumatic actuator for industrial machinery and automation systems requiring a double acting rodless cylinder with a 2-inch bore, double end mount, and 1/4 NPTF porting.

Installation Notes

Installation should be performed by a qualified mechanical or pneumatic technician familiar with compressed air systems. Depressurize and lock out the pneumatic circuit before mounting or servicing the cylinder. Ensure port fittings are compatible with NPTF tapered threads and use appropriate thread sealant rated for pneumatic service. Verify that the mounting structure can support the cylinder load and that alignment is within the manufacturer's tolerance to avoid side-loading the carriage.
