Norgren RP200X2.000-DAN Rodless Air Cylinder 2in Bore

Product Description

The NORGREN RP200X2.000-DAN is a double acting rodless air cylinder built for industrial pneumatic applications requiring reliable linear motion control. The cylinder features a 2-inch bore and a 2-inch stroke, delivering consistent actuation force at operating pressures up to 250 psi. The stainless steel body provides corrosion resistance in demanding environments. Port connections are 1/4 NPTF, compatible with standard compressed air fittings. The double end mount configuration supports secure installation in fixed-frame assemblies. This unit is sized and rated for use by maintenance technicians, automation engineers, and industrial equipment specialists working with compressed air systems.

The RP200X2.000-DAN is suited for light-duty to medium-duty industrial automation, material handling, and positioning applications. Its compact form factor and rodless design make it well suited for applications where space constraints prevent the use of a conventional rod-style cylinder. The 2-inch bore size is common in assembly line tooling, clamping fixtures, and conveyor divert systems. The double acting configuration allows powered motion in both directions, providing positive control through the full stroke length. Installation is typical in controlled industrial environments where clean, dry compressed air is supplied.

Key Features

• Double acting design provides powered actuation in both directions throughout the full 2-inch stroke
• Stainless steel body construction resists corrosion and withstands industrial wash-down conditions
• 250 psi maximum working pressure rated for standard industrial compressed air systems
• 1/4 NPTF port threads ensure leak-resistant connection with standard pneumatic fittings
• Double end mount style allows rigid, fixed-frame installation at both ends of the cylinder body
• Rod thread size of 1/2-20 and mount thread of 1-1/4-12 support standard industrial hardware

Compatibility

Designed as an OEM-style replacement or direct-install pneumatic cylinder for industrial compressed air systems requiring a double acting, rodless configuration with a 2-inch bore and double end mount.

Installation Notes

Installation of pneumatic cylinders should be performed by qualified technicians familiar with compressed air system safety. Depressurize and lock out the air supply before removing or installing any pneumatic component. Verify that the supply air is clean, dry, and lubricated as required for the application before commissioning. Ensure all port fittings and mount threads are properly torqued to fitting manufacturer specifications using appropriate thread sealant on NPTF connections.
