Norgren RP200X2.000-DAD Rodless Air Cylinder 2in Bore

Product Description

The NORGREN RP200X2.000-DAD is a double acting rodless air cylinder designed for pneumatic linear motion applications in industrial and manufacturing environments. It features a 2-inch bore and a 2-inch stroke, with a maximum working pressure of 250 psi. The body is constructed from stainless steel, making it suitable for environments where corrosion resistance is a priority. The 1/4 NPTF port allows direct connection to standard pneumatic supply lines. This cylinder is installed and serviced by industrial maintenance technicians and pneumatic system specialists.

This cylinder is suited for use in automated machinery, material handling systems, and process equipment where a compact rodless design is required. The double acting configuration allows air pressure to drive motion in both directions, providing positive control through the full stroke length. The double end mount style supports rigid structural integration into machine frames and fixtures. At 2.08 inches overall width, it fits into space-constrained assemblies where conventional rod-style cylinders would not.

Key Features

• Double acting operation for powered extension and retraction
• Stainless steel body construction for corrosion resistance
• 2-inch bore with 2-inch stroke for compact linear travel
• 250 psi maximum working pressure
• 1/4 NPTF port for standard pneumatic line connections
• Double end mount with 1-1/4-12 mount thread for rigid installation

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic rodless cylinder applications requiring a 2-inch bore double acting configuration with double end mounting.

Installation Notes

Installation should be performed by a qualified industrial maintenance technician familiar with pneumatic systems. Depressurize and lock out the pneumatic supply before removing or installing the cylinder. Ensure port connections are sealed with appropriate thread sealant compatible with NPTF fittings. Verify that mounting hardware engages the 1-1/4-12 mount thread fully and that the cylinder is aligned with the load path to prevent side loading.
