Norgren RP106X4.000-DAN Rodless Air Cylinder 250 Psi

Product Description

The NORGREN RP106X4.000-DAN is a double acting rodless air cylinder designed for linear motion applications in pneumatic systems. It features a 1-1/16 inch bore, a 4 inch stroke length, and a maximum working pressure of 250 psi. The stainless steel body provides corrosion resistance in demanding industrial environments. Ported at 1/8 NPTF, the cylinder accepts standard pneumatic fittings. Double end mounting allows for rigid, inline installation in space-constrained assemblies. This cylinder is installed by industrial maintenance technicians, pneumatic system integrators, and automation specialists.

This cylinder is suited for light-duty linear actuation tasks in industrial automation, manufacturing machinery, and process equipment. The rodless design keeps the overall footprint compact, making it a practical choice where a conventional rod-style cylinder would require too much clearance. The double acting configuration provides controlled force in both the extend and retract directions. Applications include clamping fixtures, positioning slides, and material handling mechanisms that require repeatable, bidirectional pneumatic motion.

Key Features

• Double acting operation delivers controlled force in both directions of travel
• 1-1/16 inch bore with 4 inch stroke for compact linear actuation
• Stainless steel body construction for corrosion resistance in harsh environments
• 250 psi maximum working pressure rated for standard industrial pneumatic systems
• 1/8 NPTF port accepts standard pneumatic fittings without adapters
• Double end mount with 5/8-18 mount thread for rigid inline installation

Compatibility

Designed as an OEM-style rodless pneumatic cylinder for use in industrial pneumatic circuits operating at or below 250 psi with standard 1/8 NPTF pneumatic fittings.

Installation Notes

Installation should be performed by a qualified pneumatic technician or industrial maintenance professional. Depressurize and lock out the pneumatic supply before removing or installing any cylinder. Verify that system supply pressure does not exceed the 250 psi maximum rated working pressure. Ensure all port fittings are compatible with NPTF threading and that mounting hardware engages the 5/8-18 mount threads fully before pressurizing the circuit.
