Norgren RP106X3.000-DAN Rodless Air Cylinder 1-1/16 in Bore

Product Description

The NORGREN RP106X3.000-DAN is a double acting rodless air cylinder built for pneumatic linear motion applications in industrial and mechanical systems. It features a 1-1/16 inch (1.06 inch decimal) bore, a 3 inch stroke, and a stainless steel body rated to 250 psi maximum working pressure. The double end mount configuration allows secure installation at both ends of the cylinder, making it well suited for compact actuator setups where a traditional rod-style cylinder does not fit. Licensed pneumatic technicians and industrial maintenance professionals typically install this unit in automated equipment, fixtures, and tooling assemblies.

This cylinder is designed for use in medium-duty pneumatic circuits found in manufacturing, assembly, and material handling equipment. The rodless design keeps the overall footprint compact while delivering full stroke travel. The 1/8 NPTF port accepts standard NPT fittings common in plant-air plumbing. The 6.75 inch overall length and 1.125 inch overall width make it a practical fit in tight machine frames or close-clearance slide assemblies where space is limited.

Key Features

• Double acting operation provides powered motion in both extend and retract directions
• Stainless steel body for corrosion resistance in wash-down or humid environments
• 250 psi maximum working pressure suits standard plant-air systems
• 1/8 NPTF port threads directly onto standard NPT pneumatic fittings without adapters
• Double end mount with 5/8-18 mount thread enables rigid, vibration-resistant installation
• Compact rodless design reduces total installed length compared to rod-style cylinders of equal stroke

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic actuator for double end mount rodless cylinder applications requiring a 1-1/16 inch bore, 3 inch stroke, and 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic or industrial maintenance technician. Depressurize and lock out the pneumatic circuit before removing or installing any cylinder. Confirm port connections are sealed with appropriate thread sealant rated for compressed air service, and verify that supply pressure does not exceed the 250 psi maximum working pressure rating. Inspect mounting hardware and end mounts for proper engagement before returning the system to service.
