Norgren RP106X2.000-DAN Rodless Air Cylinder 250 Psi

Product Description

The NORGREN RP106X2.000-DAN is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. It features a 1-1/16 inch bore, a 2 inch stroke, and a stainless steel body rated to 250 psi maximum working pressure. The 1/8 NPTF port accepts standard compressed-air fittings, and the double end mount configuration provides secure, balanced attachment to tooling frames and actuator assemblies. At 0.43 pounds, this is a compact, lightweight unit suited for tight-clearance applications. Installation is typically performed by automation technicians, millwrights, or pneumatic systems specialists working on production equipment or custom machinery.

This cylinder is suited for short-stroke linear actuation tasks in both light industrial and automation environments. The rodless design keeps the overall envelope compact while delivering full double acting push-pull force across the 2 inch stroke. Typical applications include pick-and-place fixtures, slide actuators, and positioning assemblies where a conventional rod cylinder would create interference. The stainless steel body resists corrosion and is appropriate for washdown-adjacent environments or installations requiring material durability.

Key Features

• Double acting operation provides powered extension and retraction
• 1-1/16 inch bore with 2 inch stroke for compact linear travel
• Stainless steel body for corrosion resistance and structural durability
• 250 psi maximum working pressure rating
• 1/8 NPTF port for standard compressed-air line connections
• Double end mount with 5/8-18 mount thread for rigid, balanced installation

Compatibility

Designed as a direct-fit rodless air cylinder replacement or new installation component for pneumatic systems requiring a 1-1/16 inch bore, 2 inch stroke, double end mount configuration with 1/8 NPTF porting.

Installation Notes

Depressurize the pneumatic circuit and lock out the air supply before removing or installing any cylinder. Verify that supply pressure does not exceed 250 psi at any point in the system. Ensure port fittings are compatible with NPTF thread form and apply appropriate thread sealant per shop practice. Mounting hardware should be torqued to the frame manufacturer's specification using the 5/8-18 mount thread interface.
