Norgren RP043X0.500-DAN Rodless Air Cylinder 250 Psi

Product Description

The NORGREN RP043X0.500-DAN is a double acting rodless air cylinder designed for compact linear motion applications in pneumatic systems. With a 0.44 inch bore and a 0.5 inch stroke, this cylinder delivers controlled bidirectional actuation using shop air or instrument air supply up to 250 psi maximum working pressure. The stainless steel body provides corrosion resistance in wash-down or humid environments. The 10-32 UNF port size suits standard small-bore pneumatic fittings. This cylinder is sized for automation, tooling, and precision positioning tasks where space is limited and a traditional rod-style cylinder is not practical. Installation and specification work is typically handled by a pneumatic systems technician or maintenance engineer.

This cylinder fits applications requiring short-stroke linear actuation in tight envelopes. The double end mount configuration allows secure axial attachment at both ends, which is common in fixture tooling, pick-and-place assemblies, and small pneumatic actuator setups. The stainless steel construction makes it suitable for light industrial, food processing adjacent, and cleanroom-compatible installations where mild corrosion resistance is required. The 7/16-20 mount thread and 10-32 rod thread size allow integration with standard pneumatic hardware and mounting blocks.

Key Features

• Double acting design allows powered actuation in both directions for positive control
• 0.44 inch bore with 0.5 inch stroke suits compact, short-travel pneumatic positioning tasks
• 250 psi maximum working pressure compatible with standard shop air systems
• Stainless steel body resists corrosion in wet or humid service environments
• 10-32 UNF port size works with common small-bore pneumatic fittings and manifolds
• Double end mount with 7/16-20 mount thread for secure axial installation in tooling fixtures

Compatibility

Designed as an OEM-style replacement or new-installation pneumatic cylinder for small-bore double acting rodless cylinder applications requiring a 0.44 inch bore, 0.5 inch stroke, 10-32 UNF port, and double end mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or maintenance professional. Depressurize and lock out the pneumatic supply line completely before removing or installing any cylinder in a live system. Ensure all fittings and port connections are properly sealed and rated for the system operating pressure before returning the circuit to service. Verify alignment of the mount threads and connected load path to avoid side-loading the cylinder body during operation.
