Norgren R40-200-BNLA Air Regulator 1/4 Npt 450 Psi Remote Pilot

Product Description

The NORGREN R40-200-BNLA is a remote pilot compressed air regulator designed for industrial pneumatic systems requiring precise downstream pressure control from a remote signal source. Built with an aluminum body, this regulator accepts a 1/4 inch NPT port connection and handles inlet supply pressures up to 450 psi. It delivers a regulated output range of 5 to 125 psi and flows up to 6.4 CFM. Licensed HVAC technicians, pipefitters, and industrial maintenance mechanics install this type of regulator where remote or automated pressure adjustment is needed without manual intervention at the regulator body itself.

This regulator is suited for compressed air distribution systems in manufacturing, process automation, and industrial plant environments. The remote pilot configuration allows pressure setpoint changes to be made from a separate pilot signal, making it appropriate for automated control panels, machine tool circuits, and pneumatic actuation systems where the regulator is mounted away from the operator. No modular manifold connection is included on this unit, and no pressure gauge is integrated into the assembly.

Key Features

• Remote pilot regulator design allows pressure control from a separate pilot signal source
• 1/4 inch NPT port sizing suits standard compressed air supply lines
• 450 psi maximum supply pressure rating for high-pressure upstream circuits
• Regulated output range of 5 to 125 psi covers a wide range of pneumatic tool and actuator requirements
• 6.4 CFM airflow capacity
• Aluminum body construction for lightweight durability
• Rated for operation at temperatures down to 0 degrees F

Compatibility

Designed as an OEM-style replacement or drop-in addition for compressed air systems using 1/4 inch NPT remote pilot regulator configurations in industrial pneumatic circuits.

Installation Notes

Installation should be performed by a qualified pipefitter or industrial maintenance mechanic familiar with compressed air system service. Depressurize and lock out the air supply line before removing any existing regulator or fitting connections. Follow applicable OSHA and ASME compressed air safety guidelines when working on systems rated above 150 psi. Verify that the pilot signal source pressure and range are compatible with this regulator before commissioning.
