Norgren ND02A-N07-AMCM0 Rodless Air Cylinder 2in Bore

Product Description

The NORGREN ND02A-N07-AMCM0 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. With a 2 inch bore and 2 inch stroke, this cylinder extends and retracts using compressed air on both sides of the piston, delivering controlled force in both directions. It handles pressures up to 250 psi and connects via a 1/4 NPT port. The clevis mount configuration allows pivoting installation, accommodating slight angular misalignment during actuation. This cylinder is installed by pneumatic system technicians and industrial maintenance professionals on automated equipment, fixtures, and machine assemblies.

This cylinder is suited for space-constrained linear actuation applications where a traditional rod-style cylinder would create interference issues. The rodless design keeps the overall package length compact relative to stroke length. Typical installation scenarios include shuttle assemblies, positioning fixtures, pick-and-place mechanisms, and material handling equipment operating on standard plant air supplies. The 1/4 NPT port size is compatible with common pneumatic fittings and tubing used in light-duty industrial and commercial automation.

Key Features

• Double acting operation provides powered force in both extend and retract directions
• 2 inch bore delivers moderate thrust output suitable for light-duty actuation tasks
• 2 inch stroke in a compact rodless configuration reduces overall installed length
• 250 psi maximum working pressure compatible with standard plant air systems
• 1/4 NPT port accommodates common pneumatic fittings and push-to-connect adapters
• Clevis mount allows pivoting attachment to reduce binding from minor misalignment

Compatibility

Designed as an OEM-style replacement or new-installation rodless pneumatic cylinder for light-duty double acting applications requiring a 2 inch bore, 2 inch stroke, and clevis mount configuration.

Installation Notes

Installation should be performed by a qualified pneumatic technician or industrial maintenance professional. Depressurize and lock out the air supply before removing or installing any cylinder in the circuit. Verify port thread type and fitting compatibility before connecting supply lines, and confirm the clevis pin and bracket are rated for the expected load. Follow applicable OSHA lockout/tagout procedures and equipment manufacturer guidelines when integrating into automated machinery.
