Norgren M00600300 Union Tee Fitting Brass 3mm 150 Psi

Product Description

The NORGREN M00600300 is a push-to-connect union tee tube fitting machined from brass for use in pneumatic and fluid distribution lines. It accepts tubes from three directions in a tee configuration, allowing a single line to branch without additional adapters or ferrule hardware. The push-to-connect mechanism seats and seals on insertion, reducing assembly time. Rated to 150 psi maximum working pressure, the fitting operates across a temperature range of 0 degrees F to 175 degrees F. Nitrile O-rings provide the internal sealing surface. The fitting is sized for 3 mm outside diameter tubing and has an overall length of 26.50 mm. It is a standard choice for general-purpose pneumatic and low-pressure fluid plumbing tasks.

This union tee fitting is suited for general-purpose pneumatic systems, instrumentation lines, and light fluid distribution circuits found in commercial and industrial equipment. It is typically installed by HVAC technicians, plumbers, and automation technicians working with small-diameter tubing in control panels, pneumatic actuator circuits, or process instrumentation runs. The compact brass body fits in tight-space installations where bulkier compression fittings are not practical.

Key Features

• Push-to-connect design allows tool-free tube insertion and secure retention
• Brass body construction for corrosion resistance in pneumatic and light-fluid service
• Nitrile O-ring sealing element rated for general-purpose media compatibility
• 150 psi maximum working pressure for pneumatic and low-pressure fluid lines
• Operates from 0 degrees F to 175 degrees F
• Compact 26.50 mm overall length suits confined installations

Compatibility

Designed for use with 3 mm outside diameter tubing in general-purpose pneumatic and fluid distribution applications.

Installation Notes

Installation does not require tools for tube insertion — ensure tube ends are cut cleanly and squarely before seating to achieve a proper seal. Depressurize and isolate the line completely before removing or installing any push-to-connect fitting. Verify that the tubing outside diameter and material are compatible with the fitting before use. Follow applicable pneumatic system codes and equipment manufacturer guidelines for pressure testing after assembly.
