Norgren DC/92100/M/1 Rodless Air Cylinder 4in Bore

Product Description

The NORGREN DC/92100/M/1 is a double acting rodless air cylinder built for industrial pneumatic motion control applications. With a 4-inch bore and a 1-inch stroke, it delivers linear actuation without an external rod extending beyond the cylinder body, making it well suited for compact or space-constrained installations. The cylinder body is constructed from stainless steel, providing corrosion resistance in demanding environments. Maximum working pressure is rated at 145 psi. The port size is 1/4 NPTF, accepting standard NPT fittings. Licensed industrial pneumatic technicians and machine builders are the typical installers for this component.

This rodless cylinder is designed for use in automated machinery, material handling systems, and industrial process equipment where a conventional rod-style cylinder would create clearance or stroke-length conflicts. The square body style simplifies mounting to machine frames and linear guide systems. Applications include pick-and-place assemblies, slide tables, and clamping fixtures in both light and heavy industrial settings where clean, repeatable linear motion is required.

Key Features

• Double acting design provides powered motion in both extend and retract directions
• 4-inch bore diameter delivers substantial force output at rated pressure
• Rodless configuration eliminates external rod overhang for space-efficient installation
• Stainless steel body construction resists corrosion in washdown or humid environments
• 1/4 NPTF port accepts standard NPT pneumatic fittings without thread sealant concerns
• Square body style allows straightforward surface and bracket mounting

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic actuator for industrial double acting rodless cylinder applications requiring a 4-inch bore and 1/4 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician or industrial maintenance professional. Shut off and bleed all compressed air supply lines before mounting or removing any pneumatic cylinder. Verify that the supply pressure does not exceed the 145 psi maximum working pressure rating. Secure all fittings and confirm port connections are leak-free before returning the system to operation.
