Norgren DC/92050/M/2 Rodless Air Cylinder 2in Bore 145psi

Product Description

The NORGREN DC/92050/M/2 is a double acting rodless air cylinder designed for linear motion applications in pneumatic systems. With a 2-inch bore and a 2-inch stroke, it delivers controlled bidirectional actuation using compressed air. The cylinder operates at a maximum working pressure of 145 psi and accepts connections through a 1/8 NPTF port. Weighing 3 pounds, this square-style cylinder suits space-constrained installations where a conventional rod-style design would be impractical. It is installed by industrial maintenance technicians, automation specialists, and pneumatic system integrators.

This cylinder is suited for light-duty to medium-duty automation tasks in manufacturing, material handling, and process control environments. The 2-inch bore size and compact 2-inch stroke make it a practical choice for short-travel actuation sequences on fixtures, clamps, slides, and positioning assemblies. The operating temperature range of 23 degrees F to 176 degrees F allows use in both ambient and mildly elevated temperature environments. The 3/8-24 rod thread facilitates straightforward connection to end fittings and load attachments.

Key Features

• Double acting design provides positive force in both extend and retract directions
• 2-inch bore delivers consistent thrust output at rated pressure
• 2-inch stroke suits short-travel linear positioning tasks
• 1/8 NPTF port ensures leak-resistant threaded connection to pneumatic supply lines
• Square style body simplifies mounting to flat surfaces and fixture plates
• Operating range of 23 degrees F to 176 degrees F supports a wide range of shop and process environments

Compatibility

Designed as an OEM-style rodless pneumatic cylinder for use in standard compressed air systems requiring a 2-inch bore double acting actuator with 1/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic technician or industrial maintenance professional. Depressurize and lock out the pneumatic supply before mounting or servicing this cylinder. Ensure all port fittings are rated for 145 psi and that supply lines are clean and dry before connection. Follow applicable OSHA lockout/tagout procedures and the cylinder manufacturer guidelines when integrating into automated machinery.
