Norgren DC/92025/M/.75 Rodless Air Cylinder 1 in Bore

Product Description

The NORGREN DC/92025/M/.75 is a double acting rodless air cylinder designed for pneumatic linear motion applications in industrial and trade environments. With a 1 inch bore and a 0.75 inch stroke, this cylinder delivers controlled bidirectional actuation using compressed air. It operates at a maximum working pressure of 145 psi and is rated for temperatures ranging from 23 degrees F to 176 degrees F. The square-style body and standard port configuration make it straightforward to integrate into pneumatic control systems. Licensed industrial mechanics and pneumatic system technicians are the typical installers of this component.

This cylinder suits compact pneumatic automation setups where a rodless design is preferred to minimize overall assembly length. The 10-32 UNF port accepts standard pneumatic fittings commonly used in light industrial and OEM equipment. The 1/4-28 rod thread provides a reliable connection point for end attachments. It is well suited for use in pneumatic actuator assemblies, fixtures, and motion control systems requiring a short, precise stroke in a confined envelope.

Key Features

• Double acting operation provides positive force in both extension and retraction directions
• 1 inch bore with 0.75 inch stroke for compact, precise linear movement
• 145 psi maximum working pressure compatible with standard shop air systems
• 10-32 UNF port size accepts common pneumatic push-to-connect and threaded fittings
• 1/4-28 rod thread for secure end-of-stroke attachment
• Square body style simplifies panel or bracket mounting
• Operating temperature range of 23 degrees F to 176 degrees F suits most indoor industrial environments

Compatibility

Designed as an OEM-style pneumatic cylinder for use in industrial automation, fixture, and motion control assemblies requiring a double acting rodless cylinder with a 1 inch bore and 10-32 UNF porting.

Installation Notes

Installation should be performed by a qualified industrial mechanic or pneumatic systems technician. Depressurize and lock out the pneumatic supply line before removing or installing any cylinder component. Confirm that supply pressure does not exceed 145 psi and that system air is clean and dry to protect internal seals. Follow applicable OSHA lockout/tagout procedures and equipment manufacturer guidelines during all service operations.
