Norgren DC/92012/M/2 Rodless Air Cylinder 0.5 in Bore

Product Description

The NORGREN DC/92012/M/2 is a double acting rodless air cylinder designed for linear motion control in pneumatic systems. With a 0.5-inch bore and a 2-inch stroke, this compact cylinder operates at pressures up to 145 psi and handles temperatures from 23 degrees F to 176 degrees F. The square-body style and 10-32 UNF port sizing make it compatible with standard pneumatic circuit assemblies. It is typically installed by industrial maintenance technicians, automation specialists, and mechanical contractors working with compressed-air motion systems.

This cylinder suits light-duty linear actuation tasks in compact pneumatic assemblies. The rodless design saves space along the stroke axis compared to traditional rod-style cylinders. The 4-40 rod thread and 10-32 UNF port allow direct integration with standard pneumatic fittings and mounting hardware. Typical applications include positioning fixtures, small actuator stages, and tooling carriages in industrial and light manufacturing environments where bore sizes in the 0.5-inch range are specified.

Key Features

• Double acting operation for powered extension and retraction
• 0.5-inch bore with 2-inch stroke length
• 145 psi maximum working pressure
• 10-32 UNF port for standard pneumatic fitting connections
• 4-40 rod thread for direct hardware integration
• Operating temperature range of 23 degrees F to 176 degrees F
• Square body style for simplified bracket and panel mounting

Compatibility

Designed as an OEM-style replacement or direct-fit component for pneumatic systems requiring a double acting rodless air cylinder with a 0.5-inch bore and 10-32 UNF port connections.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician. Depressurize and lock out the compressed-air supply before removing or installing any cylinder component. Verify that all fittings and port connections match the specified 10-32 UNF thread before pressurizing. Do not exceed the 145 psi maximum working pressure rating during operation or testing.
