Norgren C24470518 90 Swivel Elbow Fitting 5/16in Od Brass

Product Description

The NORGREN C24470518 is a push-to-connect 90-degree swivel elbow tube fitting designed for pneumatic and fluid-transfer lines in trade and industrial service applications. Constructed from brass with a nitrile O-ring seal, this fitting accepts 5/16-inch outside-diameter tubing on the push-to-connect ports and terminates with a 1/8-inch NPTF male threaded end. It is rated to 150 psi maximum working pressure and handles temperatures from 0 degrees F to 175 degrees F. The swivel design allows the threaded end to rotate during installation, reducing torque stress on connected tubing and simplifying routing in tight spaces. HVAC technicians, plumbers, and pneumatic-system mechanics are the typical installers.

This fitting is suited for residential and light commercial pneumatic control lines, compressed-air distribution, and fluid-transfer tubing runs where a 90-degree change of direction is required. The push-to-connect mechanism allows fast, tool-free tube insertion while the swivel elbow threads into a fixed 1/8-inch NPTF port on valves, manifolds, solenoids, or equipment panels. Its compact overall length of 1.16 inches makes it practical in panel-mount and tight-clearance installations common in HVAC controls and pneumatic actuator circuits.

Key Features

• Push-to-connect tube entry for fast, tool-free tube insertion and removal
• 90-degree swivel elbow allows rotation during makeup to prevent tubing stress
• Brass body construction for corrosion resistance in air and compatible fluid service
• Nitrile O-ring seal rated for 0 degrees F to 175 degrees F service range
• 150 psi maximum working pressure rating
• 1/8-inch NPTF male thread for secure, pressure-tight port connections

Compatibility

Designed as an OEM-style push-to-connect fitting for pneumatic control and fluid-transfer tubing systems accepting 5/16-inch OD tubing with a 1/8-inch NPTF male port connection.

Installation Notes
