Norgren C20600400 Union Tee Fitting 1/4 in Od Brass

Product Description

The NORGREN C20600400 is a push-to-connect union tee tube fitting designed for tube-to-tube connections in pneumatic and fluid distribution systems. Constructed from brass, it accepts 1/4-inch OD tubing on all three ports and holds a maximum working pressure of 150 psi. The push-to-connect design allows technicians to make secure, tool-free connections quickly during installation or service work. Nitrile O-rings provide a reliable seal across a broad temperature range. This fitting is a standard component in compressed air lines, instrument tubing, and light-duty fluid circuits found in HVAC, refrigeration, and industrial plumbing applications.

This fitting is suited for residential and light commercial systems where 1/4-inch OD tubing is routed through tee junctions. Common applications include pneumatic control lines, condensate management tubing, and instrument air circuits. The union tee configuration allows a single fitting to branch one supply line into two directions without additional adapters. Licensed HVAC technicians, plumbers, and mechanical contractors are the typical installers in both new construction and retrofit scenarios.

Key Features

• Push-to-connect design enables fast, tool-free tube insertion and secure retention
• Brass construction provides corrosion resistance in air and compatible fluid service
• Rated to 150 psi maximum working pressure
• Nitrile O-ring seal for reliable leak-free performance
• Operates from 0 degrees F to 175 degrees F
• Union tee configuration connects three 1/4-inch OD tube lines in a single fitting body

Compatibility

Designed as an OEM-style replacement or service fitting for pneumatic and fluid systems using 1/4-inch OD push-to-connect tubing.

Installation Notes

Installation should be performed by a licensed HVAC technician, plumber, or qualified mechanical contractor. Depressurize and isolate the system completely before removing or installing any fittings. Ensure tubing ends are cut cleanly and squarely, and that the tube is inserted fully to the fitting stop to achieve a proper seal. Verify the system does not exceed the 150 psi working pressure rating before returning it to service.
