Norgren C20230104 Stem Expander Fitting 1/4 Inch Od Brass

Product Description

The NORGREN C20230104 is a push-to-connect tube-to-stem fitting configured as a straight stem expander. It accepts tubing with a 1/4-inch outside diameter on the push-to-connect end and transitions to a 1/8-inch outside diameter stem. The body is machined from brass, rated to 150 psi maximum working pressure, and carries an operating temperature range of 0 to 175 degrees F. An integrated nitrile o-ring provides a reliable seal at the stem interface. This fitting is installed by plumbers, HVAC technicians, and fluid-system mechanics wherever a quick, tool-free tube connection to a stem-style port is required.

The C20230104 is suited for use in compressed air lines, pneumatic control circuits, fluid distribution manifolds, and light-duty hydraulic tubing runs operating within its rated pressure and temperature envelope. The straight configuration simplifies inline connections where space allows a direct tube-to-stem transition. Its compact 1.41-inch overall length makes it practical in tight panel or cabinet installations common in HVAC and industrial pneumatic applications.

Key Features

• Push-to-connect design allows tool-free tube insertion and release
• Brass body construction for corrosion resistance in air and fluid service
• Nitrile o-ring stem seal compatible with common pneumatic and hydraulic media
• 150 psi maximum working pressure rating
• Wide service temperature range: 0 to 175 degrees F
• Compact 1.41-inch overall length for tight-space installations

Compatibility

Designed as a standard push-to-connect stem expander fitting compatible with 1/4-inch OD tubing and 1/8-inch OD stem ports in pneumatic and fluid distribution systems.

Installation Notes

Installation is performed by licensed plumbers, HVAC technicians, or qualified pneumatic-system mechanics. Before connecting or disconnecting this fitting, depressurize and lock out the system per applicable safety procedures. Ensure tubing ends are cut square and deburred before insertion to achieve a full, leak-free seat. Verify system media compatibility with brass and nitrile before placing this fitting in service.
