Norgren C00821008 Push-to-connect Tube Fitting Brass

Product Description

The NORGREN C00821008 is a brass push-to-connect tube-to-tube fitting designed for use in pneumatic and fluid distribution lines. It accepts tube outside diameters of 10 millimeters on two ports and 8 millimeters on the third, making it a reducing tee-style connector. Rated to 150 psi maximum working pressure, this fitting is built for general-purpose service in compressed air, light hydraulic, and instrumentation applications. The nitrile o-ring seals provide reliable sealing across a working temperature range of 0 degrees F to 175 degrees F. Installation requires no tools beyond tube preparation — the push-to-connect mechanism locks the tube on insertion and releases with a collar push.

This fitting is suited for residential and light commercial pneumatic systems, process control plumbing, and general-purpose fluid line assemblies. It is a single-piece, all-brass body fitting appropriate for bench assembly or field installation where quick, leak-free tube connections are required. Technicians working on compressed air distribution, OEM equipment plumbing, or control panel pneumatics will find this fitting applicable to a wide range of standard tubing runs.

Key Features

• Push-to-connect design allows tool-free tube insertion and collar-actuated release
• Brass body construction for corrosion resistance in air and fluid service
• Rated to 150 psi maximum working pressure
• Nitrile o-ring seals compatible with general-purpose pneumatic and fluid media
• Operating temperature range of 0 degrees F to 175 degrees F
• Tube outside diameter ports: 10 millimeters x 10 millimeters x 8 millimeters

Compatibility

Designed for general-purpose pneumatic and fluid line applications using metric outside-diameter tubing. Compatible with tubing rated for use with push-to-connect brass fittings in compressed air and similar service.

Installation Notes

Installation should be performed by a qualified plumbing or pneumatic technician. Depressurize and isolate the line before removing or installing any fitting. Ensure tube ends are cut square, deburred, and free of contamination before insertion to achieve a proper seal. Verify that tubing outside diameter and material are rated for the system pressure and temperature before completing the connection.
