Norgren C00821000 Union Y Tube Fitting Brass 150 Psi

Product Description

The NORGREN C00821000 is a push-to-connect union Y tube fitting designed for tube-to-tube connections in pneumatic and fluid distribution lines. Constructed from brass, it accepts tubing with a 10 mm outside diameter and is rated for a maximum working pressure of 150 psi. The Y configuration splits or combines flow across three ports without requiring tools for tube insertion. It is suited for general-purpose plumbing, pneumatic control, and instrumentation applications. Licensed plumbers, HVAC technicians, and industrial maintenance technicians typically install this fitting in compressed air, water, and low-pressure fluid systems.

This fitting is intended for general-purpose use across residential, commercial, and light industrial environments. It is designed for clean, dry, or wet service lines where a Y-branch connection is needed between same-diameter tubes. The operating temperature range of 0 degrees F to 175 degrees F makes it appropriate for most indoor mechanical and process control installations. No soldering, threading, or flaring is required, making it a fast-install solution in tight service spaces.

Key Features

• Push-to-connect design allows tool-free tube insertion and removal
• Brass body construction for corrosion resistance in fluid and air service
• Rated to 150 psi maximum working pressure
• Accepts 10 mm outside diameter tubing on all three ports
• Nitrile O-ring seals for compatibility with a broad range of media
• Temperature rated from 0 degrees F to 175 degrees F

Compatibility

Designed for general-purpose tube-to-tube service as an OEM-style push-to-connect union Y fitting compatible with 10 mm outside diameter tubing in pneumatic, water, and low-pressure fluid applications.

Installation Notes

Installation does not require tools for tube insertion; ensure tubing ends are cut cleanly and squarely before seating to achieve a leak-free connection. Depressurize and isolate the line before disassembly or fitting replacement. Verify that tubing outside diameter and material are compatible with the fitting rating before commissioning. Follow applicable plumbing or pneumatic system codes for the jurisdiction in which the fitting is installed.
