Norgren C00820600 Union Y Tube Fitting Brass 6mm

Product Description

The NORGREN C00820600 is a brass union Y push-to-connect tube fitting designed for tube-to-tube connections in pneumatic and fluid distribution systems. It joins three tube lines in a Y configuration without the need for tools or thread sealant, allowing fast field assembly. Rated to 150 psi maximum working pressure and suitable for service from 0 degrees F to 175 degrees F, this fitting is built for reliable performance in light industrial, HVAC, and fluid control applications. Licensed plumbers, pipefitters, and HVAC technicians commonly install this type of fitting when routing tubing through panels, equipment enclosures, or inline distribution points.

This fitting is suited for residential and light commercial applications where 6 mm outside diameter tubing must be split or combined at a single junction point. The push-to-connect design accepts tubing with a 6 mm OD and locks it in place without soldering or compression tools. It is well-matched to pneumatic control systems, instrument air lines, and similar low-pressure fluid or air distribution circuits where a compact, leak-resistant union is required.

Key Features

• Union Y configuration connects three tube lines at one fitting body
• Brass construction for corrosion resistance and durability in air and fluid service
• Push-to-connect design allows tool-free tube insertion and removal
• Rated to 150 psi maximum working pressure
• Operating temperature range of 0 degrees F to 175 degrees F
• Nitrile O-ring seals for reliable leak-free performance

Compatibility

Designed as an OEM-style push-to-connect union Y fitting for systems using 6 mm outside diameter tubing in pneumatic or fluid distribution circuits.

Installation Notes

Installation is performed by licensed pipefitters, HVAC technicians, or pneumatic system technicians. Depressurize and isolate the line completely before removing or inserting fittings. Ensure tubing ends are cut cleanly and squarely with no burrs before insertion to maintain proper seal engagement. Follow applicable piping and mechanical codes, including ASME and local mechanical code requirements, when integrating into pressurized systems.
