Norgren C00430400 Stem Elbow Tube Fitting Brass 150 Psi

Product Description

The NORGREN C00430400 is a push-to-connect stem elbow tube fitting manufactured from brass. It connects a push-to-connect tube port to a stem port at an elbow angle, allowing directional routing of tubing in tight or angled plumbing and pneumatic assemblies. The fitting accepts a 4mm outside diameter tube on the push-to-connect side and a 4mm outside diameter stem on the opposite end. It is rated for a maximum working pressure of 150 psi and handles temperatures from 0 degrees F to 175 degrees F. The nitrile o-ring provides a reliable seal in general-purpose fluid and air handling applications. Plumbers, HVAC technicians, and industrial maintenance professionals typically install this fitting.

This fitting is suited for general-purpose pneumatic and fluid system installations where a compact elbow transition is needed between tubing and a stem-type port. Its brass construction makes it appropriate for use in air lines, water lines, and other compatible media systems in both light commercial and residential settings. The push-to-connect design allows for fast, tool-free tube insertion, making it practical for service work and new installations where quick assembly is a priority.

Key Features

• Push-to-connect tube end for fast, tool-free tube insertion
• Brass construction for durability in air and water service
• 4mm tube outside diameter and 4mm stem outside diameter
• Rated to 150 psi maximum working pressure
• Nitrile o-ring seal for reliable performance across temperature range
• Operating range of 0 degrees F to 175 degrees F

Compatibility

Designed for general-purpose pneumatic and fluid line applications where a 4mm push-to-connect tube to 4mm stem elbow transition is required.

Installation Notes

Install this fitting after depressurizing and, where applicable, draining the system completely. Ensure the tubing end is cut cleanly and squarely before insertion into the push-to-connect port to achieve a proper seal. Plumbers and HVAC technicians should verify that the connected tubing and media are compatible with brass and nitrile. Follow applicable codes such as IPC or system manufacturer guidelines for pneumatic or fluid line assembly.
