Norgren A1233A1PS-2X6 Air Cylinder 2 in Bore 6 in Stroke

Product Description

The NORGREN A1233A1PS-2X6 is a single acting rodless air cylinder designed for linear motion applications in industrial pneumatic systems. It features a 2 inch bore and a 6 inch stroke, delivering controlled actuation force up to 250 psi maximum working pressure. The 3/8 NPTF port accommodates standard pneumatic fittings, and the 7/16-20 rod thread provides a secure mechanical connection point. With a square style body and a 5/8 inch rod diameter, this cylinder is built for reliable service in production, assembly, and material handling environments. Installation and maintenance are handled by qualified pneumatic system technicians or industrial maintenance professionals.

This cylinder is suited for light-to-medium duty pneumatic automation in manufacturing, assembly lines, and similar industrial settings. The single acting configuration means it extends under air pressure and returns via spring or gravity, making it appropriate for clamping, pressing, or positioning tasks where a powered return stroke is not required. The -20 to 200 degrees F operating temperature range allows use in both ambient and moderately cold or warm environments. The 3/8 NPTF port is compatible with standard shop air supply lines and pneumatic manifold systems.

Key Features

• Single acting operation: air extends, spring or gravity returns
• 2 inch bore with 6 inch stroke for compact linear travel
• 250 psi maximum working pressure for reliable force output
• 3/8 NPTF port for leak-resistant threaded connection
• 7/16-20 rod thread for secure load attachment
• Operating range of -20 to 200 degrees F for versatile environment use

Compatibility

Designed as an OEM-style replacement or direct-fit pneumatic cylinder for industrial single acting rodless cylinder applications requiring a 2 inch bore and 6 inch stroke with 3/8 NPTF porting.

Installation Notes

Installation should be performed by a qualified pneumatic systems technician. Depressurize and lockout the air supply before removing or installing any cylinder. Verify that supply pressure does not exceed 250 psi and that all fittings are rated for the application. Ensure mounting surfaces are flat and secure to prevent misalignment that can cause premature seal wear.
