Norgren 95435504M Push-to-connect Tube Fitting 1/4in Od

Product Description

The NORGREN 95435504M is a push-to-connect tube fitting with a female NPT (FNPT) center connection, designed for inline tube-to-tube runs with a threaded branch port. Constructed from brass, it accepts 1/4-inch outside diameter tubing on both ends and threads into a 1/8-inch FNPT port. Rated to 150 psi maximum working pressure, it handles a wide service temperature range from -40 degrees F to 212 degrees F with a Buna-N O-ring seal. Licensed plumbers, pipefitters, and pneumatic system technicians install this fitting in general-purpose fluid and air distribution lines.

This fitting is suited for general-purpose pneumatic and fluid systems where a quick, tool-free tube connection is needed alongside a female NPT branch or panel-mount port. It performs in both residential and light commercial applications involving compressed air, water, and compatible process fluids. The push-to-connect mechanism allows fast field assembly without ferrules or compression sleeves, reducing installation time in tight spaces or multi-circuit manifold setups.

Key Features

• Push-to-connect ends accept 1/4-inch OD tubing without tools or ferrules
• 1/8-inch female NPT center port for inline or branch threaded connections
• Brass body for corrosion resistance in air and general-purpose fluid service
• 150 psi maximum working pressure rating
• Buna-N O-ring seal for reliable tube retention and leak-free performance
• Wide temperature range: -40 degrees F to 212 degrees F

Compatibility

Designed for general-purpose pneumatic and fluid systems using 1/4-inch OD tubing and 1/8-inch NPT threaded ports.

Installation Notes

Depressurize and isolate the system completely before removing or installing any push-to-connect fitting. Verify tubing is cut square and deburred before insertion to ensure a proper O-ring seal and full tube engagement. Thread the FNPT port connection with appropriate thread sealant tape per IPC guidelines. To release tubing, depress the collet ring evenly before pulling the tube free.
