Nordic Pure 10x16x1CustomM12+C-12 Merv 12 Carbon Filter

Product Description

The NORDIC PURE 10x16x1CustomM12+C-12 is a custom-cut, electrostatically charged pleated air filter rated MERV 12 with an activated carbon layer. It is designed for residential and light commercial HVAC systems, including forced-air furnaces and central air conditioning units. The filter captures airborne particulates while the carbon component adsorbs odors and gaseous contaminants. At a nominal size of 10x16x1 inches with an actual size of 9.5x15.5x0.75 inches, this unit ships in a 12-pack. MERV 12 filtration captures over 90 percent of particles between 3 and 10 microns and 80 to 90 percent of particles between 1 and 3 microns. Licensed HVAC technicians and experienced DIYers install this filter as a direct drop-in replacement during routine maintenance.

This filter is suited for residential homes and light commercial spaces where occupants require enhanced allergen and odor control. Targeted contaminants include lint, household dust, pollen, dust mites, pet dander, mold spores, smoke, bacteria, and viruses. The activated carbon layer adds a second stage of filtration that addresses common household odors. Because this is a custom-fabricated size, it is intended for systems where standard nominal sizes do not fit the filter slot. Nordic Pure constructs custom sizes by cutting down or combining standard filter frames, sometimes using reinforced tape, to achieve the specified dimensions.

Key Features

• MERV 12 rating captures over 90 percent of particles between 3 and 10 microns and 80 to 90 percent between 1 and 3 microns
• Activated carbon layer reduces common household odors alongside particulate filtration
• Electrostatically charged synthetic media attracts and holds fine airborne particles
• Reinforced 2-part frame construction provides added structural durability for consistent airflow support
• Custom-fabricated to nominal 10x16x1 inches with actual dimensions of 9.5x15.5x0.75 inches
• Made in the USA

Compatibility

Custom-fabricated to the nominal 10x16x1 inch size for HVAC systems and furnaces where this non-standard filter dimension is required. Verify the actual filter slot dimensions before ordering, as custom sizes are not eligible for return.

Installation Notes

Power down the furnace or air handler at the thermostat and disconnect power at the breaker before servicing the filter. Confirm the actual slot dimensions with a tape measure before installing a custom-size filter, as the actual filter measures 9.5x15.5x0.75 inches, not the full nominal size. Observe the airflow direction arrow on the filter frame and align it with the direction of airflow through the system. Nordic Pure recommends replacing this filter every 30 to 90 days depending on environmental conditions and system load.
