Product Description
The U.S. Motors 5542ET is an HVAC single-phase OAO belly band motor designed for various heating and cooling applications. This motor operates at 720 RPM and delivers performance suitable for both residential and commercial units.
- Power: 3/4 hp, 1/3 hp
- Voltage: 115/208-230
- Enclosure: OAO
Product Highlights
This motor features a belly band mount for flexible installation and offers electronically protected operation for reliable functionality.
Product Information
Standard Information
-
Brand: U.S. Motors
-
Model Number: 5542ET
Technical Specifications
-
Horsepower: 3/4 hp, 1/3 hp
-
Voltage Rating: 115/208-230 volts
-
RPM: 720
-
Frame Size: 48Y
-
Phase: Single phase
-
Frequency: 50/60 Hz
-
Full Load Amps: 8.1/6.1-5.2 & 8.9/5.7-5.1
-
Insulation Class: B
-
Enclosure: OAO - Open Air Over
-
Mounting Type: Belly Band
-
Weight: 18.0 lb
