Nidec XS13CA2JCR 1/3 HP Hazardous Location C-Face Motor 1800 RPM 115/208-230V 56C Frame

Brand: US MOTORS
SKU: XS13CA2JCR
Availability: In Stock
truck-svgrepo-com

Ships Same Day if Ordered by 12pm

$538.97
$538.97
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The Nidec XS13CA2JCR motor is a hazardous location C-face 3-phase motor. It has a power rating of 1/3 HP and operates at 1800 RPM. The motor is designed for use in hazardous environments and runs on a voltage of 115/208-230V.

  • 1/3 HP
  • 1800 RPM
  • Hazardous Location

Product Highlights

This motor is suitable for various industrial environments requiring explosion-proof equipment. It features a 56C frame and operates on 3-phase power. The unit is constructed from robust materials to ensure long-lasting performance in challenging conditions.

Product Information

Standard Information

  • Brand: Nidec
  • MPN: XS13CA2JCR

Technical Specifications

  • Electrical Type: Cap Start
  • HP: 1/3
  • Frame: 56
  • Diameter: 6.5 inches
  • Enclosure: TEFC
  • Phase: Single
  • Voltage: 115/208-230V
  • Rotation: REV
  • Overload Protector: Auto
  • Material: Rolled Steel
  • Bearings Type: Ball/Ball
  • Bearings Size: 6203/6205
  • Mounting: C-Face/Footless
  • Amperage: 6.8/3.3-3.4
