Nidec WD34C1JC Painted Washdown Motor 3/4 HP 115/208-230V Replacement MPN

Product Description

The Nidec WD34C1JC is a painted washdown motor designed for various applications requiring a robust and efficient motor. This three-quarter horsepower motor operates at a nameplate speed of three thousand six hundred revolutions per minute. It is suitable for use in environments that require reliability and durability. The motor supports dual voltage operation at one hundred fifteen and two hundred eight to two hundred thirty volts.

• Operational Features: Single-phase with capacitor-start design.
• Frame Size: Fits a standard fifty-six C frame.
• Continuous Duty: Designed for steady operational use.

Product Highlights

This washdown motor is ideal for applications like garage and gate openers, ensuring efficient operation in demanding conditions.

Product Information

Standard Information

• Manufacturer: Nidec
• Type: Electric Motor

Technical Specifications

• Power: 3/4 HP
• Speed: 3600 RPM
• Voltage: 115/208-230V
• Frame Size: 56C
• Amperage: 9.7/5.3-4.9 A
• Enclosure Type: Totally Enclosed Nonventilated
• Ambient Temperature: Max. 40 Degrees C
• Duty Cycle: Continuous
