US-Nidec U1P1DC General Purpose Motor 1HP 208-230/460 3-Phase 3600 RPM

Product Description

The US-Nidec U1P1DC General Purpose Motor is engineered for various industrial applications. This motor, model U1P1DC, operates at 1 horsepower and supports three-phase power ranging from 208 to 230/460 volts. Its 3600 RPM provides robust performance ideal for many settings.

• 1 horsepower motor
• 208-230/460 volts, three-phase
• 3600 RPM speed

Product Highlights

Key features of the US-Nidec U1P1DC motor include high efficiency, reliable performance, and versatile usage in industrial equipment such as fans, blowers, compressors, and pumps.

Product Information

Standard Information

• Brand: US-Nidec
• MPN: U1P1DC
• Applications: General industrial equipment including fans, blowers, compressors, and pumps

Technical Specifications

• Horsepower: 1
• RPM: 3600
• Voltage: 208-230/460
• Frame: 56
• Amperage: 2.9-2.7/1.4
• Enclosure: TEFC
• Phase: Three
• Material: Rolled Steel
• Bearings Type: Ball/Ball
• Mounting: C-Face / Footed
• Efficiency: 81.50%
• Insulation Class: F
• Service Factor: 1.25
• Shaft Type: Single
• Rotation: REV
