Nidec HD60P2E 60 hp 1800 RPM 364T Frame TEFC Electric Motor 208-230/460V

Product Description

The Nidec HD60P2E is a 60 hp electric motor designed for demanding industrial applications. With an 1800 RPM speed and a 364T frame, it operates efficiently on 208-230/460 volts. This model features a Totally Enclosed Fan Cooled (TEFC) design, making it suitable for harsh environments like pulp and paper plants, saw mills, chemical plants, and more.

• Corrosion-resistant paint and zinc-plated hardware
• Rigid base mount with keyed shaft
• Suitable for inverter power applications

Product Highlights

This Nidec motor provides reliable performance with features like a cast iron frame, stainless steel nameplate, and ball bearings. Its efficiency and durability make it ideal for various industrial processes requiring protection in harsh conditions.

Product Information

Standard Information

• Manufacturer: Nidec
• Brand: Nidec
• Model: HD60P2E

Technical Specifications

• Horsepower: 60 hp
• Speed: 1800 RPM
• Voltage: 208-230/460 Volts
• Frame: 364T
• Enclosure: TEFC
• Phase: Three
• Material: Cast Iron
• Amperage: 137/68 amps
• Service Factor: 1.15
• Insulation Class: F
• Weight: 640 pounds
• Dimensions: 39 inches (L) x 31 inches (W) x 27 inches (H)
