Nidec HD3P1E 3 hp 3600 RPM 184T Frame 208-230/460V TEFC Electric Motor
Nidec HD3P1E 3 hp 3600 RPM 184T Frame 208-230/460V TEFC Electric Motor

Nidec HD3P1E 3 hp 3600 RPM 184T Frame 208-230/460V TEFC Electric Motor

Brand: US MOTORS
SKU: HD3P1E
Availability: In Stock
truck-svgrepo-com

Ships via Freight in 3-5 Business Days
$457.45
$457.45
LTL Delivery

This product weighs 70 lbs and may require the use of lift gate. If you require a lift gate you will have the option to add one FREE of charge at checkout.

HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Nidec HD3P1E electric motor features a 3 hp power capacity and operates at 3600 RPM, suitable for various industrial applications. It has a 184T frame and supports 208-230/460V three-phase power.

  • 3 hp, 3600 RPM, 8.2/4.1 amps
  • NEMA 182T frame, keyed shaft
  • TEFC, reversible, rigid base mount

Product Highlights

This Nidec HD3P1E electric motor is designed for hostile duty operations with premium efficiency. The cast iron frame ensures durability, and it comes with corrosion-resistant paint, a stainless steel nameplate, and zinc-plated hardware. This motor is ideal for demanding environments such as pulp and paper plants, sawmills, and chemical plants.

Product Information

Standard Information

  • Brand: Nidec
  • Model: HD3P1E

Technical Specifications

  • Horsepower: 3 hp
  • Speed: 3600 RPM
  • Frame: 184T
  • Voltage: 208-230/460V
  • Phase: Three
  • Enclosure: TEFC
  • Material: Cast Iron
  • Efficiency: 86.50%
  • Service Factor: 1.15
  • Insulation Class: F
  • Shaft Type: Keyed
  • Weight: 70 lbs
  • Amperage: 8.2/4.1 amps
