Nidec HD32P2E Electric Motor 1.5 HP 1800 RPM 145T Frame 230/460V TEFC

Product Description

The Nidec HD32P2E Electric Motor delivers reliable performance for various industrial applications. This motor features a horsepower of 1.5 hp and operates at 1800 RPM, making it suitable for demanding environments. The motor is built with a 145T frame and runs on 230/460 volts, ensuring efficiency and durability.

• 1.5 horsepower, 1800 RPM
• 230/460 volts, three-phase
• TEFC design for enhanced protection

Product Highlights

The Nidec HD32P2E Electric Motor is ideal for use in pulp and paper plants, saw mills, mines, foundries, chemical plants, and waste management facilities. Its rigid base mount and keyed shaft provide stability and ease of installation. The TEFC (Totally Enclosed Fan-Cooled) design ensures durability in harsh conditions.

Product Information

Standard Information

• Manufacturer: Nidec
• Brand: Nidec
• Model: HD32P2E
• UPC: 786382127114

Technical Specifications

• Horsepower: 1.5 hp
• Speed: 1800 RPM
• Voltage: 230/460 volts
• Frame: 145T
• Phase: Three-phase
• Enclosure: TEFC
• Material: Cast Iron
• Current: 4.1/2.1 amps
• Mounting Type: Rigid Base
• Shaft Diameter: 7/8 inches
• Shaft Length: 2 3/8 inches
• Ambient Temperature: 40 degrees C
• Insulation Class: F
• Service Factor: 1.15
• Efficiency: 86.5%
• Amperage: 4.1/2.1 amps
